ˇ´Built in motor brake and auto-reverse mechanism helps to achieve
excellent dispensing performance.
ˇ´Built in current protection device.
ˇ´A non-contact signal control is used to control operation and brake
with voltage difference. Pin 5 controls the positive signals of the
brake while Pin 6 controls the negative signals.
ˇ´Built in optical-electrical input and output function, Pin3
0VDC~12VDC. (the power of optical-electrical associated device is
provided by the controller)
ˇ´Built in reverse current protection, over current protection and
polarity reversal protection.
ˇ´In-built front end output +5VDC used for control dry contact and
relay.
ˇ´The controller easy to remove or exchange without the need for
special tools or equipment.
